Centrifugal Process Pump

Model A

ISO Centrifugal Process Pump - Design to ISO 2858

Horizontal radially split volute casing pump in back pull out pump design with closed or semi open radial impeller, single- entry, single stage in accordance with ISO 2858 with optional leakage free hydro dynamic shaft seal

Operating Data

Pump Sizes : 32 to 350mm
Capacity : Up to 1800 m3/hr
Head : Up to 150 m
Pressure : Up to 25 bar
Temperature : Up to +250 Degree C

Applications

Aggressive organic & inorganic fluids in Chemical industry, Petrochemical industry, Sugar Industry, Distilleries, Refinery, Cellulose, food, Paper & Pulp Industry, Textile, Pharmaceuticals, Power stations, Heating, Air- conditioning.

Applications

Over decades, PSP has tapped several new industrial markets with thousands of centrifugal and positive displacement pumps running in demanding applications across the globe.
